Low Profile Parts Hopper - 57 x 49 x 34"

Reduce cleanup time in machine shops and job sites. Rolls easily underneath machinery to catch finished parts or scraps.
  • 20" hopper height.
  • All-welded steel construction.
  • Removable handle.
  • Forkliftable for elevated dumping. Simply pull cable from your forklift to release hopper. Returns to locked position when lowered to the ground.
  • Includes security chain.
  • 4" nylon casters: 2 swivel, 2 rigid.
MODEL
NO.
DESCRIPTION SUGGESTED
USE
CUBIC
YARD
CAP.
(LBS.)
FORK POCKET
CENTERS
OVERALL DIM.
L x W x H
WT.
(LBS.)
PRICE EACH IN STOCK
SHIPS TODAY
1 2+
H-5485 Low Profile Parts, Scraps 1/2 2,000 22" Wide 574934" 341 $1,425 $1,400  ADD
SHIPS UNASSEMBLED VIA MOTOR FREIGHT
DIMENSIONS:
  • Actual:
    • Overall: 57 x 48 5/8 x 34"
    • Fork Pocket Centers: 21 5/8"
  • Hopper:
    • Usable: 44 1/4 x 48 x 13 1/2" (L x W x H)
    • Height (Including Casters- Actual): 19 5/8"
  • Handle:
    • Height: 34"
    • Pipe: 1"
  • Usable Fork Pockets: 7 x 2" (W x H)
  • Security Chain: 56"
  • Pull Cable: 60"
  • Casters (Width): 2"
SIZE:
  • Will not fit through a standard doorway (32" clearance).
MATERIAL:
  • Hopper: 10 gauge steel
  • Base: 1/4" thick galvanized steel
COMPATIBILITY:
  • Not compatible with pallet trucks.
FEATURES:
  • 90° dumping angle.
  • Casters: One swivel has a brake.
CAPACITY:
  • 1/2 Cubic Yard=
    • 100 gallons
    • 13.5 Cubic feet
    • 10.85 Bushels
STYLE:
  • Hopper does not have a bumper release.
REPLACEMENT CASTERS:
  • 4" Rigid: H-5545R
  • 4" Swivel: H-5545S
  • 4" Swivel with Brake: H-5545SWB
SPECIFICATIONSMETRICIMPERIAL
VOLUME0.4 cu. M1/2 cu. yd.
CAPACITY907 Kg2,000 lbs.
FORK POCKET CENTERS56 cm Wide22" Wide
OVERALL LENGTH x WIDTH x HEIGHT145 x 124 x 86 cm57 x 49 x 34"
WEIGHT186 Kg410 lbs.
PARTS:
  • H-2108-D100 Release Lever Assembly Kit for Dumping Hoppers - 1/2 and 1 Cubic Yard
  • H-2641-SPRG Torsion Spring for Steel Dumping Hoppers
