Shrink Tunnel - 110V

Quickly shrink-wrap packages.
MODEL
NO.		 OPENING DIM.
H x W		 TEMPERATURE
RANGE		 VOLTAGE WT.
(LBS.)		 PRICE
EACH		 IN STOCK
SHIPS TODAY
H-951 6 x 16" 100° to 350°F 110V 300 $3,000  ADD
DIMENSIONS:
  • Overall:
    • With Optional Legs: 35 x 22 x 53" (L x W x H)
    • Without Legs: 35 x 22 x 24" (L x W x H)
  • Tunnel Length: 20"
  • Distance Between Rollers: 1/2"
  • Power Cable: 14'
MATERIAL:
  • Powder coated steel
TEMPERATURE:
  • Performance: Room should be above 60° F.
USAGE:
  • Will not create an airtight seal.
  • Initial Heat Control Setting: 300 - 330
  • Initial Speed Control Setting: 2 - 3 seconds
  • Can shrink up to any length.
  • Machine does not seal. Sealer must be purchased separately.
  • Use PVC bags if product is heat sensitive.
  • Light items over 5" tall may be knocked over when passing through the front or back of tunnel.
  • Conveyor Speed (Approximate):
SpeedFeet per Minute
00
18
216
324
432
543
651
760
868
976
10*85
*Too fast to shrink film.
SPECIFICATIONS:
  • 2200 W
  • 3-Prong plug
Ships Via Motor Freight
Availability: In Stock
Unit Weight: 300 lbs.
Instructions
Parts List
Catalog Page 230
Email Item
SPECIFICATIONSMETRICIMPERIAL
HEAT RANGE38° to 177°C100° to 350°F
OPENING HEIGHT x WIDTH15 x 41 cm6 x 16"
Ships Via Motor Freight
Availability: In Stock
Unit Weight: 300 lbs.
Instructions
Parts List
Catalog Page 230
Email Item
PARTS:
